Rubycon 820μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 18 (Dia.) x 40mm +105°C 18mm 7.5mm [100ZLJ820M18X40]; 172-8136
by Rubycon
0₫
Mã kho: 1728136
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 820 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 18 (Dia.) x 40mm |
| Height | 40mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 18mm |
| Maximum Operating Temperature | +105°C |
| Lifetime | 10000h |
| Lead Pitch | 7.5mm |
| Series | ZLJ |
| Ripple Current | 3.86A |
| Leakage Current | 0.01 CV or 3 μA |
| Tolerance | ±20% |
