Rubycon 220μF 100V dc Aluminium Electrolytic Capacitor, Surface Mount 18 (Dia.) x 16.5mm +105°C 18mm 6.8mm [100SGV220M18X16.5]; 172-6380
by Rubycon
0₫
Mã kho: 1726380
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 220 µF |
| Voltage | 100 V dc |
| Mounting Type | Surface Mount |
| Technology | Electrolytic |
| Dimensions | 18 (Dia.) x 16.5mm |
| Height | 16.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 18mm |
| Maximum Operating Temperature | +105°C |
| Lead Pitch | 6.8mm |
| Lifetime | 2000h |
| Series | SVG |
| Ripple Current | 440mA |
| Polarised | Polar |
| Tolerance | ±20% |
| Leakage Current | 0.01 CV or 3 μA |
