Rubycon 22μF 100V dc Aluminium Electrolytic Capacitor, Through Hole 8 (Dia.) x 11.5mm +130°C 8mm 3.5mm [100RX3022M8X11.5]; 172-7496
by Rubycon
0₫
Mã kho: 1727496
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 22 µF |
| Voltage | 100 V dc |
| Mounting Type | Through Hole |
| Technology | Electrolytic |
| Dimensions | 8 (Dia.) x 11.5mm |
| Height | 11.5mm |
| Minimum Operating Temperature | -40°C |
| Diameter | 8mm |
| Maximum Operating Temperature | +130°C |
| Lifetime | 2000h |
| Lead Pitch | 3.5mm |
| Series | RX30 |
| Tolerance | ±20% |
| Leakage Current | 0.01 CV or 3 μA |
| Ripple Current | 220mA |
