Relpol 3PDT Non-Latching Relay Plug In, 24V ac Coil, 16 A General Purpose Relay [RUC-1013-26-3024]; 123-2095
by Relpol
0₫
Mã kho: 1232095
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 24 V ac |
| Coil Power | 2.8W |
| Isolation Coil To Contact | 2.5kV ac |
| Contact Configuration | 3PDT |
| Mounting Type | Plug In |
| Switching Current | 16A |
| Terminal Type | Plug In |
| Number of Poles | 3 |
| Maximum Switching Voltage AC | 440V |
| Maximum Switching Voltage DC | 24V |
| Length | 38.6mm |
| Depth | 36.1mm |
| Maximum Switching Power AC | 4 kVA |
| Series | RUC |
| Height | 45.5mm |
| Standards Met | CE, CIK, CSA, CULus, EAC |
