Relpol DPDT Non-Latching Relay PCB Mount, 9V dc Coil, 8 A Non-Latching Relay [RM84-2012-35-1009]; 134-8377
by Relpol
0₫
Mã kho: 1348377
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 9 V dc |
| Coil Power | 400 → 480mW |
| Coil Resistance | 200 Ω |
| Isolation Coil To Contact | 5kV ac |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 8A |
| Terminal Type | PCB Pin |
| Number of Poles | 2 |
| Maximum Switching Voltage AC | 440V |
| Maximum Switching Voltage DC | 24V |
| Depth | 12.7mm |
| Maximum Switching Power AC | 2 kVA |
| Length | 29mm |
| Height | 15.7mm |
| Standards Met | CCC, CSA, CULus, EAC, VDE |
