Recom REC20 20W Isolated DC-DC Converter Through Hole, Voltage in 18 → 36 V dc, Voltage out 15V dc [REC20-2415S]; 162-2771
by Recom
0₫
Mã kho: 1622771
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 15V dc |
| Output Voltage Adjustment Range | -10 → +10% |
| Input Voltage Range | 18 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 1.6kV dc |
| Power Rating | 20W |
| Output Current | 1.34A |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Efficiency | 0.9 |
| Minimum Temperature | -40°C |
| Load Regulation | ±0.5% |
| Maximum Temperature | +100°C |
| Standards Met | CAN, CSA, CULus Recognised, EN55022, EN60950, EN61000-4-2, EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-8, IEC, IEC60950, IECEE CB SCHEME, REACH, UL, UL60950 |
| Depth | 10.2mm |
| Series | REC20 |
| Length | 50.8mm |
| Width | 25.4mm |
