Recom 2W Isolated DC-DC Converter Through Hole, Voltage in 10.8 → 13.2 V dc, Voltage out 12V dc [R12P212S/R8]; 733-1039
by Recom
0₫
Mã kho: 7331039
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | 12V dc |
| Input Voltage Range | 10.8 → 13.2 V dc |
| Input Voltage Nominal | 12 V dc |
| Isolation Voltage | 8kV dc |
| Power Rating | 2W |
| Output Current | 167mA |
| Mounting Type | Through Hole |
| Number of Outputs | 1 |
| Efficiency | 80 → 87% |
| Package | SIP 7 |
| Load Regulation | ±10% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Length | 19.5mm |
| Depth | 12.5mm |
