USB, D Sub & Computing Connectors > D Sub Connectors

ERNI TMC Series, 25 Way Right Angle Through Hole PCB D-sub Connector Plug, 2.75mm Pitch [023173]; 161-5415

0₫
(Giá chưa VAT).
Mã kho: 1615415

Liên hệ để có giá tốt (Vietnam: 0898.332.898,  E-mail: SKF@nguyenxuong.com)

THÔNG SỐ KỸ THUẬT
Number of Contacts 25
Gender Male
Body Orientation Right Angle
Mounting Type Through Hole
Pitch 2.75mm
Mounting Hardware Guide Frame, M3 Screwlocks
Termination Method Solder
Current Rating 7.5A
Housing Material PBT
Voltage Rating 1.25 kV
Length 53.0mm
Width 10.8mm
Depth 12.5mm
Dimensions 53 x 10.8 x 12.5mm
Series TMC
Series Number 23
Maximum Operating Temperature +125°C
Contact Plating Gold
Minimum Operating Temperature -65.0°C
