ERNI TMC Series, 25 Way Through Hole PCB D-sub Connector Plug, 2.84mm Pitch [023019]; 259-2365
by Provertha
0₫
Mã kho: 2592365
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Contacts | 25 |
Gender | Male |
Body Orientation | Straight |
Mounting Type | Through Hole |
Pitch | 2.84mm |
Termination Method | Solder |
Current Rating | 7.5A |
Housing Material | PBT |
Voltage Rating | 1.2 kV ac |
Length | 53.0mm |
Width | 10.8mm |
Depth | 12.5mm |
Dimensions | 53 x 10.8 x 12.5mm |
Series Number | 23 |
Minimum Operating Temperature | -65.0°C |
Maximum Operating Temperature | +125°C |
Contact Plating | Gold |
Series | TMC |
