D Sub Connectors > D Sub Connectors

ERNI TMC Series, 25 Way Through Hole PCB D-sub Connector Socket, 2.84mm Pitch, with 4-40 UNC Inserts [003626]; 170-6750

0₫
(Giá chưa VAT).
Mã kho: 1706750

Mã nhà sản xuất: 003626

Liên hệ để có giá tốt (Vietnam: 0898.332.898,  E-mail: SKF@nguyenxuong.com)

THÔNG SỐ KỸ THUẬT
Number of Contacts 25
Gender Female
Body Orientation Straight
Mounting Type Through Hole
Pitch 2.84mm
Mounting Hardware 4-40 UNC Inserts
Termination Method Solder
Current Rating 5.0A
Housing Material PBT
Voltage Rating 1.0 kV
Length 53.0mm
Width 11.0mm
Depth 12.5mm
Dimensions 53 x 11 x 12.5mm
Series TMC
Maximum Operating Temperature +125°C
Series Number 3
Minimum Operating Temperature -65.0°C
Contact Plating Gold
