2 Way Preci-Dip Straight Through Hole 2.54mm SIL Socket, Solder, 3A 100 V ac, 150 V dc [310-87-102-01-640101]; 702-2969
by Preci-Dip
0₫
Mã kho: 7022969
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 2 |
| Contact Material | Beryllium Copper, Brass |
| Contact Plating | Gold, Tin |
| Pitch | 2.54mm |
| Orientation | Straight |
| Termination Method | Solder |
| Mounting Type | Through Hole |
| Housing Material | Glass Fibre Reinforced PCT |
| Current Rating | 3A |
| Voltage Rating | 100 V ac, 150 V dc |
| Dimensions | 5.08 x 2.54 x 4.2mm |
| Depth | 4.2mm |
| Length | 5.08mm |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55°C |
| Width | 2.54mm |
