Norcomp 7 Way Right Angle PCB D-sub Connector Plug, with 4-40 Inserts/Board Lock [684M7W2103L461]; 174-8748
by Norcomp
0₫
Mã kho: 1748748
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 7 |
| Gender | Male |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| D Connector Type | Mixed Contact D-Sub |
| Termination Method | Solder |
| Mounting Hardware | 4-40 Inserts/Board Lock |
| Current Rating | 5 A, 40.0A |
| Mixed Contact Layout | 7W2 |
| Housing Material | Steel |
| Voltage Rating | 1.0 kV |
| Length | 39.2mm |
| Width | 6.9mm |
| Depth | 12.5mm |
| Dimensions | 39.2 x 6.9 x 12.5mm |
| Minimum Operating Temperature | -55.0°C |
| Maximum Operating Temperature | +125°C |
| Contact Material | Copper Alloy |
| Series Number | 684M |
| Contact Plating | Gold Flash |
