Norcomp 15 Way Vertical PCB D-sub Connector Socket, 2.29mm Pitch, with 4-40 Spacer/Board Lock [180-M15-213R911]; 174-8819
by Norcomp
0₫
Mã kho: 1748819
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 15 |
| Gender | Female |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Pitch | 2.29mm |
| D Connector Type | High Density D-Sub |
| Mounting Hardware | 4-40 Spacer/Board Lock |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 1.0 kV |
| Length | 30.8mm |
| Width | 12.5mm |
| Depth | 11.8mm |
| Dimensions | 30.8 x 12.5 x 11.8mm |
| Contact Plating | Gold Flash |
| Maximum Operating Temperature | +125°C |
| Minimum Operating Temperature | -55.0°C |
| Series Number | 180 |
| Contact Material | Brass |
