Norcomp 44 Way Vertical PCB D-sub Connector Plug, 2.29mm Pitch, with 4-40 Spacer/Board Lock [180-044-113R911]; 174-8512
by Norcomp
0₫
Mã kho: 1748512
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 44 |
| Gender | Male |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Pitch | 2.29mm |
| D Connector Type | High Density D-Sub |
| Termination Method | Solder |
| Mounting Hardware | 4-40 Spacer/Board Lock |
| Current Rating | 3.0A |
| Housing Material | Steel |
| Voltage Rating | 500.0 V |
| Length | 53.0mm |
| Width | 12.6mm |
| Depth | 12.5mm |
| Dimensions | 53 x 12.6 x 12.5mm |
| Maximum Operating Temperature | +100°C |
| Minimum Operating Temperature | -50.0°C |
| Series Number | 180 |
| Contact Plating | Gold Flash |
| Contact Material | Brass |
