Norcomp 15 Way Right Angle PCB D-sub Connector Plug, 2.77mm Pitch, with 4-40 StandOffs/Board Lock [178-015-613R571]; 174-8492
by Norcomp
0₫
Mã kho: 1748492
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 15 |
| Gender | Male |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.77mm |
| D Connector Type | Dual Ports D-Sub |
| Termination Method | Solder |
| Mounting Hardware | 4-40 StandOffs/Board Lock |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 1.0 kV |
| Length | 38.99mm |
| Width | 25.4mm |
| Depth | 31.75mm |
| Dimensions | 38.99 x 25.4 x 31.75mm |
| Contact Material | Brass |
| Minimum Operating Temperature | -55.0°C |
| Contact Plating | Gold Flash |
| Maximum Operating Temperature | +105°C |
| Series Number | 178 |
