Norcomp 9 Way Right Angle PCB D-sub Connector Socket, 2.54mm Pitch [173-E09-213R001]; 174-8773
by Norcomp
0₫
Mã kho: 1748773
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 9 |
| Gender | Female |
| Body Orientation | Right Angle |
| Mounting Type | Through Hole |
| Pitch | 2.54mm |
| D Connector Type | Standard D-Sub |
| Termination Method | Solder |
| Current Rating | 5.0A |
| Housing Material | Steel |
| Voltage Rating | 500.0 V |
| Length | 30.734mm |
| Width | 12.446mm |
| Depth | 12.446mm |
| Dimensions | 30.734 x 12.446 x 12.446mm |
| Series Number | 173 |
| Contact Material | Brass |
| Contact Plating | Gold Flash |
| Maximum Operating Temperature | +100°C |
| Minimum Operating Temperature | -50.0°C |
