Microchip PIC18LF66K40-I/MR, 8bit PIC18 Microcontroller, 64MHz, 64 kB Flash, 64-Pin QFN [PIC18LF66K40-I/MR]; 134-5639
by Microchip
0₫
Mã kho: 1345639
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | PIC18 |
| Package Type | QFN |
| Mounting Type | Surface Mount |
| Pin Count | 64 |
| Device Core | PIC18 |
| Data Bus Width | 8bit |
| Program Memory Size | 64 kB |
| Maximum Frequency | 64MHz |
| RAM Size | 3.562 kB |
| Number of PWM Units | 1 |
| ADC Channels | 45 |
| Number of SPI Channels | 2 |
| Typical Operating Supply Voltage | 1.8 → 3.6 V |
| Program Memory Type | Flash |
| Number of UART Channels | 5 |
| Number of Timers | 2 |
| Pulse Width Modulation | 1(2 x 10 bit) |
| Dimensions | 9 x 9 x 0.95mm |
| Timers | 1(4 x 8 bit), 1(5 x 16 bit) |
| Number of USART Channels | 5 |
| Width | 9mm |
| PWM Channels | 2 |
| Number of I2C Channels | 2 |
| Height | 0.95mm |
| Timer Resolution | 8 bit, 16 bit |
| ADC Resolution | 10bit |
| Maximum Operating Temperature | +85 °C |
| Length | 9mm |
| ADCs | 1(45 x 10 bit) |
| Number of ADC Units | 1 |
| Instruction Set Architecture | RISC |
| PWM Resolution | 10bit |
| Minimum Operating Temperature | -40 °C |
