Microchip PIC16LF19156-I/MV, 8bit 8 bit CPU Microcontroller, 32MHz, 28 kB Flash, 28-Pin UQFN [PIC16LF19156-I/MV]; 144-9522
by Microchip
0₫
Mã kho: 1449522
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Family Name | PIC16LF191 |
Package Type | UQFN |
Mounting Type | Surface Mount |
Pin Count | 28 |
Device Core | 8 bit CPU |
Data Bus Width | 8bit |
Program Memory Size | 28 kB |
Maximum Frequency | 32MHz |
RAM Size | 2.048 kB |
Number of PWM Units | 1 |
ADC Channels | 20 |
Number of SPI Channels | 1 |
Typical Operating Supply Voltage | 2.3 → 5.5 V |
Number of UART Channels | 2 |
Number of I2C Channels | 1 |
Number of Timers | 2 (16-bit), 2 (8-bit) |
Timer Resolution | 8 bit, 16 bit |
Height | 0.5mm |
Number of LIN Channels | 1 |
PWM Channels | 2 |
Width | 4mm |
Number of USART Channels | 2 |
Timers | 1 (2 x 16 bit), 1 (2 x 8 bit) |
Dimensions | 4 x 4 x 0.5mm |
ADC Resolution | 12bit |
Minimum Operating Temperature | -40 °C |
Pulse Width Modulation | 1 (2 x 10 bit) |
Program Memory Type | Flash |
PWM Resolution | 10bit |
Instruction Set Architecture | RISC |
Number of ADC Units | 1 |
Maximum Operating Temperature | +85 °C |
Length | 4mm |
ADCs | 1 (20 x 12 bit) |
