Microchip PIC16F1618-I/P, 8bit PIC Microcontroller, 32MHz, 7 kB Flash, 20-Pin PDIP [PIC16F1618-I/P]; 144-5882
by Microchip
0₫
Mã kho: 1445882
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | PIC16F |
| Package Type | PDIP |
| Mounting Type | Through Hole |
| Pin Count | 20 |
| Device Core | PIC |
| Data Bus Width | 8bit |
| Program Memory Size | 7 kB |
| Maximum Frequency | 32MHz |
| RAM Size | 512 B |
| Number of PWM Units | 1 |
| ADC Channels | 12 |
| Typical Operating Supply Voltage | 2.3 → 5.5 V |
| Length | 26.42mm |
| Maximum Operating Temperature | +85 °C |
| Number of ADC Units | 1 |
| Program Memory Type | Flash |
| Number of Timers | 3, 4 |
| ADCs | 1(12 x 10 bit) |
| Dimensions | 26.42 x 6.6 x 3.68mm |
| PWM Resolution | 10bit |
| Minimum Operating Temperature | -40 °C |
| Instruction Set Architecture | RISC |
| Pulse Width Modulation | 2(10 bit) |
| Timers | 3 x 16 bit, 4 x 8 bit |
| ADC Resolution | 10bit |
| Width | 6.6mm |
| Timer Resolution | 8 bit, 16 bit |
| Height | 3.68mm |
| PWM Channels | 2 |
