Microchip Technology PIC16C63A-20I/SP, 8bit Microcontroller, 20MHz, 4 kwords Flash, 28-Pin PDIP [PIC16C63A-20I/SP]; 177-0510
by Microchip
0₫
Mã kho: 1770510
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | PIC16C |
| Package Type | PDIP |
| Mounting Type | Through Hole |
| Pin Count | 28 |
| Data Bus Width | 8bit |
| Program Memory Size | 4 kwords |
| Maximum Frequency | 20MHz |
| RAM Size | 192 B |
| Number of SPI Channels | 1 |
| Typical Operating Supply Voltage | 2.5 → 6 V |
| Number of Timers | 2 |
| Number of UART Channels | 1 |
| Maximum Operating Temperature | +85 °C |
| Length | 35.18mm |
| Instruction Set Architecture | RISC |
| Program Memory Type | Flash |
| Height | 3.43mm |
| Width | 7.49mm |
| Timer Resolution | 8 bit, 16 bit |
| Timers | 1 (1 x 16 bit), 1 (2 x 8 bit) |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 35.18 x 7.49 x 3.43mm |
