Microchip Technology PIC12F1571-E/SN, 8bit Microcontroller, 32MHz, 1 kwords Flash, 8-Pin SOIC [PIC12F1571-E/SN]; 177-0491
by Microchip
0₫
Mã kho: 1770491
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Family Name | PIC12F |
Package Type | SOIC |
Mounting Type | Surface Mount |
Pin Count | 8 |
Data Bus Width | 8bit |
Program Memory Size | 1 kwords |
Maximum Frequency | 32MHz |
RAM Size | 128 B |
Number of PWM Units | 1 |
ADC Channels | 4 |
Typical Operating Supply Voltage | 2.3 → 5.5 V |
ADCs | 1 (4 x 10 bit) |
Timer Resolution | 8 bit, 16 bit |
Height | 1.5mm |
PWM Channels | 3 |
Width | 3.9mm |
Timers | 1 (2 x 8 bit), 1 (4 x 16 bit) |
Dimensions | 4.9 x 3.9 x 1.5mm |
Pulse Width Modulation | 1 (3 x 16 bit) |
Program Memory Type | Flash |
Number of Timers | 2 |
Length | 4.9mm |
Maximum Operating Temperature | +125 °C |
Number of ADC Units | 1 |
Instruction Set Architecture | RISC |
PWM Resolution | 16bit |
Minimum Operating Temperature | -40 °C |
ADC Resolution | 10bit |
