Microchip Technology MIC5201-3.3YS, LDO Regulator, 200mA, 3.3 V, ±2% 3 + Tab-Pin, SOT-223 [MIC5201-3.3YS]; 177-0446
by Microchip
0₫
Mã kho: 1770446
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Output Voltage | 3.3 V |
Dropout Voltage at Maximum Current | 400 mV @ 200 mA |
Output Type | Fixed |
Package Type | SOT-223 |
Maximum Output Current | 200mA |
Mounting Type | Surface Mount |
Minimum Input Voltage | 2.5 V |
Maximum Input Voltage | 26 V |
Pin Count | 3 + Tab |
Number of Outputs | 1 |
Quiescent Current | 0.01µA |
Accuracy | ±2% |
Minimum Operating Temperature | -40 °C |
Maximum Operating Temperature | +125 °C |
Height | 1.6mm |
Line Regulation | 0.004 |
Length | 6.5mm |
Dimensions | 6.5 x 3.5 x 1.6mm |
Load Regulation | 0.003 |
Width | 3.5mm |
