Microchip Technology MCP16251T-I/CH, Boost Converter, Synchronous Boost Regulator 250mA Adjustable, 575 kHz 6-Pin [MCP16251T-I/CH]; 177-2833
by Microchip
0₫
Mã kho: 1772833
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Regulator Function | Synchronous Boost Regulator |
| Maximum Output Current | 250mA |
| Number of Outputs | 1 |
| Line Regulation | 0.4 %/V |
| Load Regulation | 0.015 |
| Mounting Type | Surface Mount |
| Package Type | SOT-23 |
| Pin Count | 6 |
| Output Type | Adjustable |
| Maximum Switching Frequency | 575 kHz |
| Switching Regulator | Yes |
| Dimensions | 3.1 x 1.8 x 1.3mm |
| Height | 1.3mm |
| Minimum Input Voltage | 0.82 V |
| Minimum Output Voltage | 1.8 V |
| Length | 3.1mm |
| Maximum Operating Temperature | +85 °C |
| Width | 1.8mm |
| Maximum Input Voltage | 5.5 V |
| Minimum Operating Temperature | -40 °C |
| Maximum Output Voltage | 5.5 V |
