Microchip Technology ATTINY461A-XU, 8bit AVR Microcontroller, 20MHz, 4 kB Flash, 20-Pin TSSOP [ATTINY461A-XU]; 133-1654
by Microchip
0₫
Mã kho: 1331654
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | AVR |
| Package Type | TSSOP |
| Mounting Type | Surface Mount |
| Pin Count | 20 |
| Device Core | AVR |
| Data Bus Width | 8bit |
| Program Memory Size | 4 kB |
| Maximum Frequency | 20MHz |
| RAM Size | 256 B |
| Number of PWM Units | 1 |
| ADC Channels | 11 |
| Typical Operating Supply Voltage | 1.8 → 5.5 V |
| Number of Timers | 2 |
| ADCs | 1(11 x 10 bit) |
| Length | 6.6mm |
| Maximum Operating Temperature | +85 °C |
| Program Memory Type | Flash |
| Number of ADC Units | 1 |
| Pulse Width Modulation | 1(6 Channel) |
| Instruction Set Architecture | RISC |
| PWM Channels | 6 |
| Width | 4.5mm |
| Height | 1.05mm |
| Timer Resolution | 8 bit, 10 bit, 16 bit |
| ADC Resolution | 10bit |
| Timers | 1 x 8/10 bit, 1 x 8/16 bit |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 6.6 x 4.5 x 1.05mm |
