Microchip Technology ATTINY26L-8MU, 8bit AVR Microcontroller, 8MHz, 2 kB Flash, 32-Pin MLF [ATTINY26L-8MU]; 133-1622
by Microchip
0₫
Mã kho: 1331622
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | AVR |
| Package Type | MLF |
| Mounting Type | Surface Mount |
| Pin Count | 32 |
| Device Core | AVR |
| Data Bus Width | 8bit |
| Program Memory Size | 2 kB |
| Maximum Frequency | 8MHz |
| RAM Size | 128 B |
| Number of PWM Units | 1 |
| ADC Channels | 11 |
| Typical Operating Supply Voltage | 2.7 → 5.5 V |
| Maximum Operating Temperature | +85 °C |
| Program Memory Type | Flash |
| Number of ADC Units | 1 |
| Instruction Set Architecture | RISC |
| Pulse Width Modulation | 1(4 Channel) |
| Number of Timers | 1 |
| ADCs | 1(11 x 10 bit) |
| Length | 5.1mm |
| Height | 0.95mm |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 5.1 x 5.1 x 0.95mm |
| Timers | 1 (2 x 8 bit) |
| Timer Resolution | 8bit |
| PWM Channels | 4 |
| ADC Resolution | 10bit |
| Width | 5.1mm |
