Microchip Technology ATMEGA8515-16JU, 8bit AVR Microcontroller, 16MHz, 8 kB Flash, 44-Pin PLCC [ATMEGA8515-16JU]; 131-0340
by Microchip
0₫
Mã kho: 1310340
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Family Name | ATmega |
| Package Type | PLCC |
| Mounting Type | Surface Mount |
| Pin Count | 44 |
| Device Core | AVR |
| Data Bus Width | 8bit |
| Program Memory Size | 8 kB |
| Maximum Frequency | 16MHz |
| RAM Size | 512 B |
| Number of PWM Units | 1 |
| Typical Operating Supply Voltage | 4.5 → 5.5 V |
| Length | 16.66mm |
| Maximum Operating Temperature | +85 °C |
| Number of Timers | 2 |
| Program Memory Type | Flash |
| Timer Resolution | 8 bit, 16 bit |
| Height | 4.06mm |
| Width | 16.66mm |
| Minimum Operating Temperature | -40 °C |
| Dimensions | 16.66 x 16.66 x 4.06mm |
| PWM Channels | 3 |
| Pulse Width Modulation | 1(3 Channel) |
| Instruction Set Architecture | RISC |
