Lapp High Temperature Wire 0.5 mm² CSA, Black 100m Reel, ÖLFLEX HEAT Series [48001]; 724-4462
by Lapp
0₫
Mã kho: 7244462
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Cross Sectional Area | 0.5 mm² |
| Sheath Colour | Black |
| American Wire Gauge | 20 AWG |
| Insulation Material | Silicone |
| Resistant To | Chemicals, Oils |
| Core Strands | 19/0.25 mm |
| Minimum Operating Temperature | -50°C |
| Maximum Operating Temperature | +180°C |
| Operating Temperature Range | -50 → +180 °C |
| Length | 100m |
| Outer Diameter | 2.1mm |
| Voltage Rating | 300 V |
| Shield Type | Unshielded |
| Size of Strands | 0.25 mm |
| Conductor Material | Copper |
| Number of Strands | 19 |
| Series | ÖLFLEX HEAT |
| Cable Shape | Single Core |
