4 Way PCB DIP Switch 4PST, Raised Actuator [DBS 61004]; 918-9884
0₫
Mã kho: 9189884
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Contact Configuration | 4PST |
Contact Current Rating | 25 (Switching) mA, 100 (Non-Switching) mA |
Contact Material | Gold over Nickel Plated |
Number of Positions | 4 |
Mounting Type | PCB |
Actuator Type | Raised |
Package Style | DIP |
Mechanical Life | 5000Operations |
Maximum Operating Temperature | +85°C |
Minimum Operating Temperature | -40°C |
Operating Temperature Range | -40 → +85°C |
Dielectric Strength | 500V dc |
Voltage Rating | 24 V dc, 50 V dc |
