8 Way PCB DIP Switch 8PST, Flat Actuator [DBS 60008]; 918-9880
0₫
Mã kho: 9189880
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | 8PST |
| Contact Current Rating | 25 (Switching) mA, 100 (Non-Switching) mA |
| Contact Material | Beryllium Copper, Brass |
| Number of Positions | 8 |
| Mounting Type | PCB |
| Actuator Type | Flat |
| Package Style | DIP |
| Mechanical Life | 5000Operations |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Dielectric Strength | 500V dc |
| Voltage Rating | 24 V dc, 50 V dc |
