IXYS MDI75-12A3, Y4 M5 IGBT Module, 90 A max, 1200 V, Panel Mount [MDI75-12A3]; 168-4497
by IXYS
0₫
Mã kho: 1684497
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Transistor Configuration | Single |
| Configuration | Single |
| Maximum Continuous Collector Current | 90 A |
| Maximum Collector Emitter Voltage | 1200 V |
| Maximum Gate Emitter Voltage | ±20V |
| Channel Type | N |
| Mounting Type | Panel Mount |
| Package Type | Y4 M5 |
| Pin Count | 7 |
| Dimensions | 94 x 34 x 30mm |
| Height | 30mm |
| Length | 94mm |
| Maximum Operating Temperature | +150 °C |
| Minimum Operating Temperature | -40 °C |
| Width | 34mm |
