Harting 2134 Series, Right Angle M12 to Straight M12 Cable assembly, 4 Core , 5m Cable [21348487491050]; 877-4881
by HARTING
0₫
Mã kho: 8774881
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Connector A | Right Angle M12 |
Connector B | Straight M12 |
Length | 5m |
Number of Cores | 4 |
Connector A Number of Contacts | 4 |
Connector B Number of Contacts | 4 |
Sheath Colour | Black |
IP Rating | IP67 |
Cable Shape | Multicore |
Cross Sectional Area | 0.34 mm² |
American Wire Gauge | 22 |
Shielding | Unshielded |
Maximum Operating Temperature | +80°C |
Minimum Operating Temperature | -25°C |
Connector B Housing Gender | Plug |
Standards Met | IEC 61076-2-101, ISO/IEC 11 801, ISO/IEC 24 702, RoHS Compliant |
Series | 2134 |
Sheath Material | Polyurethane PUR |
Connector A Housing Gender | Socket |
