Harting D-sub Series 2.77mm Pitch 25 Way IDC D-sub Connector, Socket, Glass Filled Thermoplastic Shell [09663187500]; 139-3670
by HARTING
0₫
Mã kho: 1393670
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Contacts | 25 |
Gender | Female |
Body Orientation | Straight |
Mounting Type | Cable Mount |
Pitch | 2.77mm |
Termination Method | IDC |
Current Rating | 2.0A |
Housing Material | Glass Filled Thermoplastic |
Voltage Rating | 1.0 kV |
Length | 53.05mm |
Width | 12.55mm |
Depth | 17.1mm |
Dimensions | 53.05 x 12.55 x 17.1mm |
Maximum Operating Temperature | +125°C |
Series | D-Sub |
Minimum Operating Temperature | -55.0°C |
Contact Material | Copper Alloy |
