Harting D-Sub High Density Series, 26 Way Through Hole PCB D-sub Connector Socket, 2.29mm Pitch [09562517513]; 923-1874
by HARTING
0₫
Mã kho: 9231874
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Number of Contacts | 26 |
| Gender | Female |
| Body Orientation | Straight |
| Mounting Type | Through Hole |
| Pitch | 2.29mm |
| Mounting Hardware | Boardlocks, 4-40 UNC Female Screwlocks |
| Termination Method | Solder |
| Current Rating | 2.0A |
| Housing Material | Steel |
| Length | 39.2mm |
| Width | 10.74mm |
| Depth | 12.55mm |
| Dimensions | 39.2 x 10.74 x 12.55mm |
| Minimum Operating Temperature | -55.0°C |
| Contact Material | Copper Alloy |
| Contact Plating | Gold |
| Maximum Operating Temperature | +105°C |
| Series Number | 956 |
| Series | D-Sub High Density |
