![HARTING 09562517512 9230660](http://nguyenxuong.com/cdn/shop/products/R6927295-20_b668d697-a380-40d1-ac5b-36ccb3445d6d_444x342.jpg?v=1594452142)
Harting 26 Way Through Hole PCB D-sub Connector Socket, 2.29mm Pitch, with 4-40 UNC Threaded Inserts, Boardlocks [09562517512]; 923-0660
by HARTING
0₫
Mã kho: 9230660
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Number of Contacts | 26 |
Gender | Female |
Body Orientation | Straight |
Mounting Type | Through Hole |
Pitch | 2.29mm |
Termination Method | Solder |
Mounting Hardware | Boardlocks, 4-40 UNC Threaded Inserts |
Current Rating | 2.0A |
Housing Material | Steel |
Length | 39.5mm |
Width | 11.0mm |
Depth | 12.93mm |
Dimensions | 39.5 x 11 x 12.93mm |
Contact Material | Copper Alloy |
Maximum Operating Temperature | +105°C |
Contact Plating | Gold |
Minimum Operating Temperature | -55.0°C |
