Genteq 80μF Polypropylene Capacitor PP 240V ac ±6% Tolerance GEM III 97F8000 Series [97F8048]; 908-4372
by Genteq
0₫
Mã kho: 9084372
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 80 µF |
| Voltage | 240 V ac |
| Tolerance | ±6% |
| Series | GEM III 97F8000 |
| Lead Pitch | 20.57mm |
| Height | 98.55mm |
| Dimensions | 2.62 (Dia.) x 3.88in |
| Dielectric | Metallised Polypropylene |
| Dielectric Material Family | Polypropylene (PP) |
| Equivalent Series Resistance | 16.4mΩ |
| Terminal Type | Quick Connect |
| Dissipation Factor | 0.001 |
| Maximum Operating Temperature | +70°C |
| Minimum Operating Temperature | -40°C |
