Genteq 3μF Polypropylene Capacitor PP 1 kV dc, 440 V ac ±6% Tolerance GEM III 97F5000 Series [97F5437]; 908-4240
by Genteq
0₫
Mã kho: 9084240
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 3 µF |
| Voltage | 1 kV dc, 440 V ac |
| Tolerance | ±6% |
| Series | GEM III 97F5000 |
| Lead Pitch | 20.57mm |
| Length | 54.86mm |
| Depth | 33.27mm |
| Height | 53.85mm |
| Dimensions | 2.16 x 1.31 x 2.12in |
| Dielectric | Metallised Polypropylene |
| Minimum Operating Temperature | -30°C |
| Terminal Type | Quick Connect |
| Dielectric Material Family | Polypropylene (PP) |
| Dissipation Factor | 0.003 |
| Maximum Operating Temperature | +70°C |
