3 Output 55W DC to DC Converter, Flyback, Power Over Ethernet, Power Sourcing Equipment, Powered Devices [B82802A0055A325]; 162-0295
by EPCOS
0₫
Mã kho: 1620295
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Secondary Voltage Rating | 3.3 (Output 2) V, 5 (Output 1) V, 12 (Output 3) V |
| Primary Voltage Rating | 36 → 60V dc |
| Power Rating | 55W |
| Number of Outputs | 3 |
| Mounting Type | Surface Mount |
| Application | DC to DC Converter, Flyback, Power Over Ethernet, Power Sourcing Equipment, Powered Devices |
| Inductance | 22µH |
| Termination Type | Gullwing |
| Length | 32.6mm |
| Dimensions | 32.6 x 27 x 14.8mm |
| Isolation Voltage | 1.5kV ac |
| Leakage Inductance | 1.2µH |
| Core Type | EFD |
| Standards Met | JEDEC J-STD-020D, RoHS Complaint |
| Construction | Enclosed |
| Maximum Temperature | +125°C |
| Secondary DC Resistance | 0.003 (Output 3) Ω, 0.04 (Output 1) Ω, 0.05 (Output 2) Ω |
| Turns Ratio | 1:2.33:0.66:6.67 |
| Minimum Temperature | -40°C |
| Maximum Operating Frequency | 100kHz |
| Primary DC Resistance | 15mΩ |
