EPCOS Standard Series Disc Varistor 460pF 100A, Clamping 1355V, Varistor 820V [B72220S0511K101]; 138-9291
by EPCOS
0₫
Mã kho: 1389291
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Varistor Voltage | 820V |
| Maximum AC Voltage Rating | 510Vrms |
| Maximum DC Voltage Rating | 670V |
| Clamping Voltage | 1355V |
| Clamping Current | 100A |
| Energy | 190J |
| Series | Standard |
| Maximum Surge Current | 6500A |
| Capacitance | 460pF |
| Length | 21.5mm |
| Depth | 26mm |
| Thickness | 7.1mm |
| Dimensions | 21.5 x 7.1 x 26mm |
| Lead Pitch | 3.5 mm, 10 mm |
