Capacitor PP Metalized 0.22uF 250V 5% [B32652A3334J000]; 194-3695
by EPCOS
0₫
Mã kho: 1943695
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Capacitance | 330 nF |
| Voltage | 160 V ac, 250 V dc |
| Mounting Type | Through Hole |
| Tolerance | ±5% |
| Series | B32652 |
| Automotive Standard | AEC-Q200D |
| Lead Pitch | 15mm |
| Length | 18mm |
| Depth | 7mm |
| Height | 12.5mm |
| Dimensions | 18 x 7 x 12.5mm |
| Dielectric | Polypropylene |
| Maximum Operating Temperature | +110°C |
| Dielectric Material Family | Polypropylene (PP) |
| Dissipation Factor | 1 x 10^-3% |
| Lead Length | 6mm |
| Lead Diameter | 0.8mm |
