| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Input Voltage Range | 90 → 264 V ac |
| Output Voltage Rating | 24 V dc |
| Output Current Range | 3.75A |
| Input Connector | IEC320-C8 |
| Output Connection Type | 2.54 x 5.49 mm Centre Positive |
| Number of Outputs | 1 |
| Load Regulation Range | ±5% |
| Overall Depth | 29.2mm |
| Overall Width | 58mm |
| Cable Length | 1000mm |
| Maximum Temperature | +50°C |
| Operating Temperature Range | 0 → +50 °C |
| Minimum Temperature | 0°C |
| Overall Length | 133mm |
| Efficiency | 0.92 |
| Weight | 300g |
| Overall Dimensions | 133 x 58 x 29.2mm |
| Energy Efficiency Level | III |
