RR HV n/c 5kV 12V coil standard UL [DBR71205U]; 189-2504
by Cynergy3
0₫
Mã kho: 1892504
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Coil Voltage | 12V dc |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 0.125 |
| Maximum Switching Current DC | 0.125 |
| Maximum Switching Voltage AC | 1000V |
| Maximum Switching Voltage DC | 1000V |
| Coil Resistance | 240 Ω |
| Length | 60mm |
| Height | 18.5mm |
| Depth | 15.8mm |
| Dimensions | 60 x 15.8 x 18.5mm |
| Isolation Coil To Contact | 17kV |
| Contact Resistance | 50 mΩ |
| Contact Material | Rhodium |
| Maximum Operating Temperature | +70°C |
| Terminal Type | PCB Pin |
| Life | 10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles |
| Operating Time Including Bounce | 2ms |
| Relay Switching Classification | General Purpose Relay |
| Number of Poles | 1 |
| Special Features | Choice of 10kV, Excellent AC Characteristics, Low Contact Resistance, PCB or Panel Mount, 7.5kV or 5kV Isolation |
| Minimum Operating Temperature | -20°C |
| Maximum Switching Power DC | 50 W |
| Operating Temperature Range | -20 → +70°C |
| Electrical Life | 10^6 (50W Switching) cycles, 10^9 (Dry Switching) cycles |
