4 Way Through Hole Rotary Switch SPST, Knurled Slotted Shaft Actuator [220ADC04]; 123-4584
by CTS
0₫
Mã kho: 1234584
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | SPST |
| Contact Current Rating | 100 mA |
| Contact Material | Beryllium Copper |
| Number of Positions | 4 |
| Mounting Type | Through Hole |
| Actuator Type | Knurled Slotted Shaft |
| Package Style | DIP |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Operating Temperature Range | -40 → +85°C |
| Voltage Rating | 50V dc |
| Dielectric Strength | 250V ac |
