3 Way Surface Mount DIP Switch Single Pole Single Throw (SPST) [219-3MST]; 177-4340
by CTS
0₫
Mã kho: 1774340
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Contact Configuration | Single Pole Single Throw (SPST) |
| Contact Current Rating | 0.1 (Switching) mA, 100 (Non Switching) mA, 100 (Switching) mA |
| Contact Material | Beryllium Copper |
| Number of Positions | 3 |
| Mounting Type | Surface Mount |
| Package Style | DIP |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -55°C |
| Operating Temperature Range | -55 → +85°C |
| Voltage Rating | 5 V dc, 20 V dc, 50 (Non Switching) V dc |
| Dielectric Strength | 500V dc |
