4 Way Surface Mount DIP Switch Single Pole Single Throw (SPST) [218-4LPSTJ]; 177-4274
by CTS
0₫
Mã kho: 1774274
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Contact Configuration | Single Pole Single Throw (SPST) |
Contact Current Rating | 25 (Switching) mA, 100 (Non Switching) mA |
Contact Material | Beryllium Copper |
Number of Positions | 4 |
Mounting Type | Surface Mount |
Package Style | DIP |
Maximum Operating Temperature | +85°C |
Minimum Operating Temperature | -55°C |
Operating Temperature Range | -55 → +85°C |
Dielectric Strength | 350V ac |
Voltage Rating | 24 V dc, 50 (Non Switching) V dc |
