Cosel 25.2W Isolated DC-DC Converter Through Hole, Voltage in 36 → 75 V dc, Voltage out ±12V dc [ZUW254812]; 138-776
by Cosel
0₫
Mã kho: 138776
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Output Voltage | ±12V dc |
| Input Voltage Range | 36 → 75 V dc |
| Power Rating | 25.2W |
| Output Current | 1A |
| Input Voltage Nominal | 48 V dc |
| Isolation Voltage | 500V ac |
| Mounting Type | Through Hole |
| Number of Outputs | 2 |
| Minimum Temperature | -20°C |
| Maximum Temperature | +71°C |
| Depth | 8.5mm |
| Length | 65mm |
