Chinfa, AMR2 DIN Rail Power Supply, 15V dc Output Voltage, 1.6A Output Current [AMR2-15]; 896-2228
by Chinfa
0₫
Mã kho: 8962228
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| AC or DC Input Voltage | Ac |
| AC or DC Output Voltage | Dc |
| Input Voltage | 90 → 264V ac |
| Output Voltage | 15 V dc |
| Output Current | 1.6 A |
| Power Rating | 24W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Height | 91mm |
| Width | 35mm |
| Mounting Type | DIN Rail Mount |
| Depth | 57mm |
| Minimum Temperature | -40°C |
| Ripple And Noise | 50mV |
| MTBF | 814000h |
| Series | AMR2 |
| Maximum Temperature | +71°C |
| Special Features | Internal Input Filter |
