Belden Red, 0.52 mm² Hook Up Wire 83007 Series , 305m [83007 0021000]; 136-6337
by Belden
0₫
Mã kho: 1366337
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
THÔNG SỐ KỸ THUẬT | |
---|---|
Cross Sectional Area | 0.52 mm² |
Sheath Colour | Red |
American Wire Gauge | 20 AWG |
Core Strands | 19/0.20 mm |
Insulation Material | TFE |
Outer Diameter | 1.47mm |
Length | 305m |
Voltage Rating | 600 V ac |
Conductor Material | Copper |
Wire Style | UL1213 |
Maximum Operating Temperature | +200°C |
Fire Behaviour | Flame Retardant |
Series | 83007 |
Minimum Operating Temperature | -70°C |
Standards Met | MIL-W-16878/4, NEMA HP3 |
Insulation Wall Thickness | 0.2mm |
