Absolute magnetic encoder SSI shaft 12mm [EAM580-BAC.5B4G.14130.A]; 189-2687
by Baumer
0₫
Mã kho: 1892687
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Encoder Technology | Magnetic |
| Maximum Revolutions | 6000rpm |
| Shaft Type | Hollow shaft |
| Supply Voltage | 4.5 → 30 V dc |
| Shaft Diameter | 12mm |
| Resolution | MT 13 bit, ST 14 bit |
| IP Rating | IP65 |
| Interface | SSI-Gray |
| Overall Width | 58mm |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Series | EAM580 |
| Connection Type | Flange connector M12 |
| Mounting Type | Blind Hollow Shaft Flange |
