AVX Tantalum Capacitor 3.3μF 25V dc MnO2 Solid ±20% Tolerance TAP Series [TAP335M025CCS]; 166-7919
by AVX
0₫
Mã kho: 1667919
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | MnO2 |
| Capacitance | 3.3 µF |
| Voltage | 25 V dc |
| Mounting Type | Through Hole |
| Equivalent Series Resistance | 5Ω |
| Lead Pitch | 5mm |
| Tolerance | ±20% |
| Height | 9mm |
| Dimensions | 4.5 (Dia.) x 9mm |
| Series | TAP |
| Electrolyte Type | Solid |
| Minimum Operating Temperature | -55°C |
| Tolerance Plus | 0.2 |
| Dissipation Factor | 0.06 |
| Leakage Current | 0.6 μA |
| Tolerance Minus | -0.2 |
| Terminal Type | Through Hole |
| Diameter | 4.5mm |
| Maximum Operating Temperature | +125°C |
| Lead Diameter | 0.5mm |
