EPCOS Tantalum Capacitor 47μF 20V dc Tantalum Solid ±10% Tolerance TAJ Series [TAJC476K020RNJ]; 136-0302
by AVX
0₫
Mã kho: 1360302
Liên hệ để có giá tốt (Vietnam: 0898.332.898, E-mail: SKF@nguyenxuong.com)
| THÔNG SỐ KỸ THUẬT | |
|---|---|
| Technology | Tantalum |
| Capacitance | 47 µF |
| Voltage | 20 V dc |
| Mounting Type | Surface Mount |
| Package/Case | 6032-28 |
| Equivalent Series Resistance | 500mΩ |
| Automotive Standard | AEC-Q200 |
| Lead Pitch | 2.9mm |
| Tolerance | ±10% |
| Length | 6mm |
| Depth | 3.2mm |
| Height | 2.6mm |
| Dimensions | 6 x 3.2 x 2.6mm |
| Series | TAJ |
| Electrolyte Type | Solid |
| Tolerance Minus | -0.1 |
| Polarised | Polar |
| Leakage Current | 9.4 μA |
| Dissipation Factor | 0.06 |
| Maximum Operating Temperature | +125°C |
| Terminal Type | SMT |
| Tolerance Plus | 0.1 |
| Surge Voltage | 26V |
| Dielectric Material Family | Tantalum |
| Minimum Operating Temperature | -55°C |
